1.Film width from 1,000mm to 3,500mm 2.Finished film 2 layers: Bubble layer + Base layer 3.Bubble film thickness from 30gsm to 120gsm 4.Suitable raw material: LDPE/LLDPE(Virgin and 100% recycled material both ok) LDPE MFI (Melt Flow Index): 2.0 ~ 2.5 LLDPE MFI (Melt Flow Index): 2.0 ~ 3.0 5.Default bubble round shape Φ10mm 6.Maximum rewinding diameter: 1200mm(accept large diameter customization) 7.Default voltage 3phase 4line 380v 50hz(accept voltage customization)

1.Film width from 1,000mm to 3,500mm 2.Finished film 3 layers: PE front layer + bubble layer + base layer 3.Bubble film thickness from 30gsm to 120gsm 4.Suitable raw material: LDPE/LLDPE(Virgin and 100% recycled material both ok) LDPE MFI (Melt Flow Index): 2.0 ~ 2.5 LLDPE MFI (Melt Flow Index): 2.0 ~ 3.0 5.Default bubble round shape Φ10mm 6.Maximum rewinding diameter: 1200mm(accept large diameter customization) 7.Default voltage 3phase 4line 380v 50hz(accept voltage customization)

1.Film width from 1,000mm to 3,500mm 2.Finished film 5 layers: PE front layer + bubble layer + base layer + laminated layer 3.The laminated layer can be Aluminized foil, MPET foil, Kraft paper, EPE foam, BOPP film etc. 4.Bubble film thickness from 40gsm to 180gsm 5.Suitable raw material: LDPE/LLDPE(Virgin and 100% recycled material both ok) LDPE MFI (Melt Flow Index): 2.0 ~ 2.5 LLDPE MFI (Melt Flow Index): 2.0 ~ 3.0 6.Default bubble round shape Φ10mm 7.Maximum rewinding diameter: 1500mm 8.Default voltage 3phase 4line 380v 50hz(accept voltage customization)

1.Film width from 1,000mm to 3,500mm 2.Finished film 5 layers: laminated layer + PE front layer + bubble layer + base layer + laminated layer 3.The laminated layer can be Aluminized foil, MPET foil, Kraft paper, EPE foam, BOPP film etc. 4.Bubble film thickness from 40gsm to 180gsm 5.Suitable raw material: LDPE/LLDPE(Virgin and 100% recycled material both ok) LDPE MFI (Melt Flow Index): 2.0 ~ 2.5 LLDPE MFI (Melt Flow Index): 2.0 ~ 3.0 6.Default bubble round shape Φ10mm 7.Maximum rewinding diameter: 1200mm(accept large diameter customization) 8.Default voltage 3phase 4line 380v 50hz(accept voltage customization)

1.Film width from 1,000mm to 3,500mm 2.Finished film 7 layers: laminated layer + base layer + bubble layer + PE middle layer + bubble layer + base layer + laminated layer 3.The laminated layer can be Aluminized foil, MPET foil, Kraft paper, EPE foam, BOPP film etc. 4.Bubble film thickness from 30gsm to 300gsm 5.Suitable raw material: LDPE/LLDPE(Virgin and 100% recycled material both ok) LDPE MFI (Melt Flow Index): 2.0 ~ 2.5 LLDPE MFI (Melt Flow Index): 2.0 ~ 3.0 6.Default bubble round shape Φ10mm 7.Maximum rewinding diameter: 1500mm 8.Default voltage 3phase 4line 380v 50hz(accept voltage customization)
